Vue3中怎么实现拖拽和缩放自定义看板vue-grid-layout

npm install vue-grid-layout@3.0.0-beta1 --save

// 将自动注册所有组件为全局组件import keycloakInit from '@/utils/util.keycloak'import VueGridLayout from 'vue-grid-layout' const app = createApp(App)app.use(store)app.use(router)app.use(ElementPlus)app.use(VueGridLayout)app.mount('#app')

<template>    <div class="nav-wrapper-b">        <div class="bar-title-b">            {{getChangeLine + ' ' + barTitle}}        </div>        <div class="time-b">            <span >{{ date }} {{ time }}</span>            <div >                <el-button v-if="isEditDraggable"                           type="success"                           size="small"                           @click="saveDragDataHome">保存                </el-button>                <el-button v-else                           type="primary"                           size="small"                           @click="editDragDataHome">布局                </el-button>            </div>        </div>    </div>    <div class="home-container-b">        <!--********************** 实现自定义组件 *********************-->        <div class="drag-body" :class="isEditDraggable ? 'drag-body-edit' : ''">            <grid-layout :layout.sync="layoutDraggableList"                         :col-num="100"                         :row-height="5"                         :is-draggable="draggableLayout"                         :is-resizable="resizableLayout"                         :vertical-compact="true"                         :use-css-transforms="true">                <grid-item v-for="item in layoutDraggableList"                           :static="false"                           :x="item.x"                           :y="item.y"                           :w="item.w"                           :h="item.h"                           :i="item.i"                           >                    <!--测试组件-->                    <div class="layout-component top-left-first-components"                         v-if="item.i == 'topLeftFirst'">                        <box-container-is>                            00001                        </box-container-is>                    </div>                    <!--前五组件-->                    <div class="layout-component"                         v-if="item.i == 'topLeftSecond'">                        <box-container :boxTitle="'测试1'">                            00002                        </box-container>                    </div>                    <!--前五-->                    <div class="layout-component"                         v-if="item.i == 'topLeftThird'">                        <box-container :boxTitle="'测试2'">                           00003                        </box-container>                    </div>                    <!--信息组件-->                    <div class="layout-component"                         v-if="item.i == 'topRightFirst'">                        <box-container-is>                            00004                        </box-container-is>                    </div>                    <!--组件-->                    <div class="layout-component"                         v-if="item.i == 'topRightSecond'">                        <box-container>                            <topRightSecondBHome></topRightSecondBHome>                        </box-container>                    </div>                    <!--组件-->                    <div class="layout-component"                         v-if="item.i == 'topRightThird'">                        <box-container-is>                            <topRightThirdBHome></topRightThirdBHome>                        </box-container-is>                    </div>                </grid-item>            </grid-layout>        </div>    </div></template> <script setup>    import emitter from '@/utils/eventbus'    import {getDate, getTime, getTimeHours} from "@/utils/date";    import {useRoute, useRouter} from "vue-router";    import boxContainer from "@/components/boxContainer/index";    import boxContainerIs from "@/components/boxContainer/index1";    import {        workOrderLine,        topRightSecondBHome,        topRightThirdBHome,    } from "./components";    import {computed, ref} from "vue";    import {getCurrentInstance, nextTick} from "@vue/runtime-core";    import {onBeforeUnmount, onMounted, watch} from "vue";    import {saveTemplateApi} from '@/api/workOrderLineApi'    import {ElMessage} from "element-plus";     const {proxy} = getCurrentInstance()    //年月日    const date = ref(getDate());    //时分秒    const time = ref(getTime());    const getChangeLine = ref('')    const hours = ref(getTimeHours())    const barTitle = ref("")    const router = useRouter();     /*____________________________主页拖拽布局开始_______________________________*/    let isEditDraggable = ref(false)    const draggableLayout = ref(false)    const resizableLayout = ref(false)    const layoutDraggableList = ref([])     //点击编辑布局    function editDragDataHome() {        isEditDraggable.value = true    }     //保存布局    function saveDragDataHome() {        isEditDraggable.value = false        console.log(layoutDraggableList.value)        saveTemplateApi(layoutDraggableList.value).then(response => {            if (response.code == 200) {                ElMessage({                    message: '模板布局已保存成功',                    type: 'success',                    duration: 6 * 1000                })            }        })    }     /*_____________________________主页拖拽布局结束______________________________*/     //模拟后端请求到的数据    let demoData = ref({        "id": 162,        "subjectId": 161,        "name": "主页",        "title": "生产分析",        "description": "第一个看板菜单信息",        "templateList": [            {                "id": 163,                "titleName": "人员信息",                "disabled": true,                "i": "topLeftFirst",                "x": 0,                "y": 0,                "w": 41,                "h": 10,                "menuId": 162            },            {                "id": 164,                "titleName": "前五",                "disabled": true,                "i": "topLeftSecond",                "x": 0,                "y": 10,                "w": 41,                "h": 21,                "menuId": 162            },            {                "id": 165,                "titleName": "吸嘴-抛料率前五",                "disabled": true,                "i": "topLeftThird",                "x": 0,                "y": 31,                "w": 41,                "h": 21,                "menuId": 162            },            {                "id": 166,                "titleName": "",                "disabled": true,                "i": "topRightFirst",                "x": 41,                "y": 0,                "w": 59,                "h": 10,                "menuId": 162            },            {                "id": 167,                "titleName": "",                "disabled": true,                "i": "topRightSecond",                "x": 41,                "y": 10,                "w": 59,                "h": 23,                "menuId": 162            },            {                "id": 168,                "titleName": "",                "disabled": true,                "i": "topRightThird",                "x": 41,                "y": 33,                "w": 59,                "h": 19,                "menuId": 162            }        ]    })    initialHeightFun(demoData.value)     //根据高度进行调整尺寸    function initialHeightFun(data) {        nextTick(() => {            layoutDraggableList.value = data.templateList            barTitle.value = data.title        })    }     onBeforeUnmount(() => {})     //监听拖拽功能    watch(isEditDraggable, (res) => {        draggableLayout.value = !draggableLayout.value;        resizableLayout.value = !resizableLayout.value;    })</script> <style lang="scss" scoped>    /*----------------拖拽样式开始----------------*/    .drag-body {        width: 100%;        height: 100%;    }     .layout-component {        width: 100%;        height: 100%;        display: flex;        flex-wrap: wrap;        align-content: space-between;    }     .layout-component-low-warning-second {        width: 95%;        height: 100%;        margin-right: 1%;        float: left;    }     .layout-component-low-warning-text {        width: 4%;        height: 100%;        float: right;    }     .layout-component-low-throwing-second {        width: 100%;        height: 100%;    }     .drag-body-edit {        .vue-grid-item:not(.vue-grid-placeholder) {            outline: 2px solid rgba(255, 96, 28, 0.71);        }    }     .vue-grid-item {        box-sizing: border-box !important;    }     .vue-grid-layout {        background: url("~@/assets/image/bg1.png");        -moz-background-size: 100% 100%;        background-size: 100% 100%;    }     ::v-deep .vue-resizable-handle {        background: url("~@/assets/image/ic_show_more.png") no-repeat 100% 100%;        padding: 0 3px 3px 0;        background-origin: content-box;        -webkit-box-sizing: border-box;        position: absolute;        width: 45px;        height: 45px;        bottom: 0;        right: 0;    }     .vue-grid-item:not(.vue-grid-placeholder) {        //border: 1px solid #409eff;        color: #ffffff;    }     .vue-grid-item .resizing {        opacity: 0.9;    }     .vue-grid-item .static {        background: transparent;    }     .vue-grid-item .text {        font-size: 24px;        text-align: center;        position: absolute;        top: 0;        bottom: 0;        left: 0;        right: 0;        margin: auto;        height: 100%;        width: 100%;    }     .vue-grid-item .no-drag {        height: 100%;        width: 100%;    }     .vue-grid-item .minMax {        font-size: 12px;    }     .vue-grid-item .add {        cursor: pointer;    }     /*----------------拖拽样式结束----------------*/     .nav-wrapper-b {        height: 60px;        line-height: 60px;        width: 100%;        background: url("~@/assets/image/top.png") no-repeat;        background-size: 100% 100%;        text-align: center;        position: relative;        color: #d5dfe8;        font-family: "黑体";         .bar-title-b {            font-size: 32px;            color: #ffffff;            font-weight: bolder;        }         .time-b {            position: absolute;            right: 1%;            top: 50%;            transform: translateY(-35%);            font-family: "Time Number";            font-weight: bold;            font-size: 29px;            width: 35%;        }         .mapChoose-b {            position: absolute;            left: 22px;            bottom: 15px;            color: #eee;        }    }     .home-container-b {        width: 100%;        height: 100%;        position: relative;        margin-top: 0;    }     .nav_btn {        position: absolute;        top: 5px;        width: 50%;        height: auto;    }</style>
